2026 Easy Success Juniper JN0-106 Exam in First Try

Best JN0-106 Exam Dumps for the Preparation of Latest Exam Questions

Juniper JN0-106 Exam Syllabus Topics:

Topic	Details
Topic 1	Configuration Basics: Covers the essential steps for configuring a Junos device from factory default, including user accounts, interfaces, authentication, system services like NTP and SNMP, and configuration archival.
Topic 2	User Interfaces: Covers how to navigate and use the Junos CLI and J-Web interface, including configuration management, output filtering, and working with active versus candidate configurations.
Topic 3	Operational Monitoring and Maintenance: Covers the tools and procedures used to monitor, maintain, and troubleshoot Junos devices, including show monitor commands, network utilities, OS upgrades, and password recovery.
Topic 4	Junos OS Fundamentals: Covers the architecture of Junos OS, focusing on the separation of control and forwarding planes and how traffic is processed by the routing and packet-forwarding engines.

NO.88 Exhibit:

Referring to the exhibit, which route will be selected for a packet destined to IP address 10.50.10.55?

Route 0.0.0.0/0 will be selected using next hop 203.0.113.1 because the default route matches all destinations and has been active the longest.

Route 10.50.0.0/16 will be selected using next hop 192.168.1.10 because OSPF has a better preference value than BGP.

Route 10.50.10.0/24 will be selected using next hop 192.168.1.20 because it has the longest prefix match for the destination address.

Route 10.0.0.0/8 will be selected using next hop 192.168.1.1 because it was learned from the static routing protocol which has the lowest preference value.

NO.89 Click the Exhibit button.

Referring to the exhibit, you are sending traffic to a network that is not directly connected to the ge-0/0/10 interface.
In this situation, which IP address will be used?

10.20.30.1

203.0.113.2

172.16.100.3

192.168.2.1

NO.90 Which two statements are examples of exception traffic? (Choose two.)

An IP packet with the Router Alert option set in the IP options field.

SSH traffic to the local Junos OS device.

An IP packet that has the IP precedence CoS bits of 111 in the ToS field.

SSH traffic to a remote server on the Internet.

NO.91 Which statement is correct when Router R1 receives a packet from User A destined for User B as shown in the exhibit?

Router R1 replaces the destination IP address in the packet with the IP address of Router R2.

Router R1 leaves the packet unchanged.

Router R1 replaces the destination MAC address in the packet with the MAC address of Router R2.

Router R1 replaces the destination MAC address in the packet with the MAC address of User B.

NO.92 Which statement accurately describes the purpose of route preference in Junos OS?

It sets the metric for forwarding traffic through the Packet Forwarding Engine.

It determines which route is selected as active when multiple routes to the same destination exist.

It controls the redistribution of routes between routing instances.

It determines the maximum number of routes that can be installed in the routing table.

NO.93 Which command would compare the candidate configuration with the active configuration before committing the changes?

[edit]
user@router# show | compare

[edit]
user@router# rollback 0

user@router > show configuration | compare rollback 0

user@router > show configuration | compare

NO.94 Which two statements are correct about MAC addresses? (Choose two.)

Switches use the Address Resolution Protocol table to assign MAC addresses to network interface cards in the forwarding frame.

The source and destination MAC addresses always remains static to the final destination.

The MAC address identifies the physical hardware.

Switches use the destination MAC address to identify the next-hop destination and to change the destination MAC address in the frame.

NO.95 Which two external authentication methods does Junos support for administrative access?
(Choose two.)

TACACS+

NIS

RADIUS

ACE

NO.96 Your routing policy has three terms. A route matches the first term with an accept action. In this scenario, what happens next?

The route is rejected by default.

The route is evaluated by the second term.

The route is sent to the next policy chain.

The route is accepted and no further terms are evaluated.

NO.97 You need to recover the root password on a Junos router without losing the current configuration settings. Which three statements describe what you should perform in this scenario? (Choose three.)

Enter and commit the new root password.

Load the factory-default configuration.

Upgrade the Junos OS to the latest version.

Hit the space bar and enter recovery when prompted.

Use a console connection to reboot the device.

NO.98 You successfully committed a configuration change. You now realize an issue exists and must revert back to the previous configuration. Which command entered in configuration mode will accomplish this task when committed?

show | compare

save config

rollback 0

rollback 1

NO.99 Your system administrator notified the infrastructure team that all server NICs will be moving to jumbo frames. All of the NICs used by servers are 1 gigabit. The starting frame size will be 4K.
The exact frame size may change depending on testing results. In this scenario, which choice would provide a flexible solution?

Create a group that adjusts MTU size on 1 gigabit interfaces and apply at the interfaces level.

Apply the MTU to each interface family for each 1 gigabit interface.

Set the app-engine compute-cluster Ethernet MTU size for the Junos VM.

Use the system internet-options path-mtu-discovery to dynamically adjust MTU.

NO.100 In Junos OS, what is the function of the candidate configuration database compared to the active configuration database in system operations?

Stores logs

Holds pending configuration changes

Maintains routing tables

Controls packet forwarding

NO.101 Which service does RADIUS provide?

routing

authentication

DNS resolution

time synchronization

NO.102 Which two statements accurately describe the relationship between the routing table and the forwarding table on a Junos device? (Choose two.)

The routing table resides in the data plane for fast lookups.

The routing table selects the best route based on routing information.

The forwarding table is built from the routing table.

The routing table is built from the forwarding table.

NO.103 Which prompt indicates that you are using configuration mode?
